Platinum | SNAP-LOCK

General Use & Method of Application

The Snap-Lock panels must be installed in a sequential pattern. Application of a Platinum Metals approved underlayment prior to panel installation is recommended when installed over a solid substrate.

• Install in accordance with industry-recognized sheet metal practices.
• Cut, form, and fasten using conventional hand or power tools.
• For best results cutting tool edges should be kept sharp, clean, properly dressed, and closely aligned.
• Fabrication and erection can be accomplished with strippable plastic film in place. Film should be removed from areas of concealed or joined pieces.

Storage

The Platinum Snap-Lock metal panels should be stored in a well-ventilated, dry place where no moisture can contact them. Moisture (from rain, snow, condensation, etc.) trapped between layers of material may cause water stains or white rust, which can affect the service life of the material and will detract from its appearance. If outdoor storage cannot be avoided, protect the panels with a ventilated canvas or waterproof paper cover. Do not use plastic, which can cause condensation. Keep the material off the ground in an inclined position with an insulator such as wood. Protective film may degrade or become brittle with long-term exposure to direct sunlight.

Precautions

• Protective film may degrade or become brittle with exposure to direct sunlight. Therefore, it must be removed immediately.
• Product should not be used in areas of high abrasion or where it is subject to mechanical damage.
• Product is pre-finished material; care must be exercised during fabrication and erection to avoid surface damage.
• Platinum Metals recommends a minimum bend radius of 2T for .032 and .040 materials and a 3T bend radius for any material .050 or greater. Anything less than these minimum bend radii can cause crazing to the material.
• Attention should be paid to good house-keeping practices.
• Avoid dragging sheets over surfaces which may scratch or mar the finish.
• For general sheet metal use in building applications.
• Do not cut with power saws or abrasive blades.

Product Size

Panel Height: 12" / 16" / 20" / Custom

Seam Height: 1.75"

Minimum Panel Length: 36"

Maximum Panel Length: 50' / Custom

Product Data

Minimum Slope: 3:12

Tapered Panels: Yes

Radiused Panels: No

Stiffening Ribs: Optional

Striations: Optional

Standard Panel Surface: Smooth

Technical Information

Uplift Resistance: UL 580 Class 90

Structural Performance: ASTM E330 and E1592

Air Infiltration: ASTM E283 and E1680

Water Penetration: ASTM E331 and E1646

Impact Resistance: PA 201

Wind-Driven Rain: TAS 100

NOTE: Testing is not applicable for all combinations of substrates, materials, and dimensions. All construction assemblies must be installed in accordance with the testing assembly.

Metal Specifications | Aluminum

Thickness:

• 0.032" (0.81mm)
• 0.040" (1.02mm)

Base Metal: Aluminum

Thermal Expansion: 12.6 x 10(^-6) in/in/F˚(22.2 m/m.K x 10(^-6))

Available Finishes:

• Anodized
• Fluropon®
• Unpainted/Mill Finish


Metal Specifications | Galvanized Steel

Thickness:

• 26 ga. (0.48 mm)
• 24 ga. (0.64 mm)

Mod. Of Elasticity: 10.0 x 10(^3) x KSI (68.9 MPa)

Base Metal: AISA-G90 Galvanized Steel

Thermal Expansion: 06.7 x 10(^-6) in/in/F˚ (13.9 m/m.K x 10(^-6))

Mod. Of Elasticity: 29.0 x 10(^6) x KSI (200 GPa)

Available Finishes:

• G90- Clear Acrylic Coated
• Fluropon®


Metal Specifications | Galvalume Steel

Thickness:

• 26 ga. (0.46 mm)
• 24 ga. (0.64 mm)

Base Metal: AZ50 Galvalume®

Thermal Expansion: 06.7 x 10(^-6) in/in/F˚ (13.9 m/m.K x 10(^-6))

Mod. Of Elasticity: 29.0 x 10(^6) x KSI (200 GPa)

Available Finishes:

• Acrylume® Clear Acrylic Coated
• Fluropon®
